BASIC INFORMATION

Basic operations

Mainly use the remote control to operate this unit. The function buttons on the front panel may also
fulfill part of the operations. The feedback information of the system is mainly displayed on the TV
screen, and part of the information is displayed on the VFD on the front panel.

To switch mode , press: [PLAY] button, [SOURCE] button,[EDIT] button, [DISC OP] button,

[SETUP] button.

In playback, recording, editing and disc operation modes, system can be controlled by “control menu”.
In playback/recording mode, the menu can be displayed by [DISPLAY] button. First pressing the
[DISPLAY] button, a text information bar showing the current working information will appear, and
secondly pressing the button will display the control menu. The control menu will appear
automatically when you enter editing mode/disc operation mode. In the control menu, you can move
focus by cursor buttons to select a sub item to perform a corresponding function.

You can configure the system in setup mode. Pressing [SETUP] button can enter this mode, In setup
mode, the control menu is always shown. Pressing [SETUP] button again to exit.
Make a timer record task in timer task setting mode. Pressing [TIMER] button can enter this mode.
Pressing [TIMER] button in this mode can exit.

This area shows current working mode

This area shows corresponding working information

The text information bar when system is in recording mode

Monitor Front S-VIDEO(No signal) SP

The control menu when system is in recording mode

RECORD (DVD+RW)

MODE

SOURCE

QUALITY

REC TO

New Title

Front S-VIDEO

DVD-VIDEO

TRICK

TITLE

The operating functions for this unit are classified into six modes:

PLAYBACK MODE, RECORDING MODE, EDITING MODE, DISC OPERATION MODE, SETUP MODE

and TIMER TASK SETTING MODE.
