3. Pull out plunger using a pair of pliers.
4. To remove funnel, you will need a deep socket wrench and funnel
removal tool.
5. Reassemble in reverse order.
6. Temperature setting must be checked by an installer before use.
See temperature adjustment below.
After reassembling go back to thermal actuator section and make
sure it is sitting in its holder properly.
Temperature Adjustment
n
Temperature setting for LFMM430 Series Valves:
1. Turn off re-circulation pump (if one is in the system).
2. Open up enough fixtures to meet minimum flow requirement of:
LFMM431 = 3 gpm (11 Lpm)
LFMM432 = 4 gpm (15 Lpm)
LFMM433 = 5 gpm (19 Lpm)
LFMM434 = 7 gpm (26 Lpm)
LFMM435 = 10 gpm (38 Lpm)
3. Loosen locknut. (see Fig. 1)
4. Turn temperature adjustment screw counterclockwise to
increase or clockwise to decrease the outlet temperature.
(see Fig. 1)
Please allow valve temperature to settle in before making your
next adjustment.
5. When desired temperature is set, tighten the locknut. Turn recir-
culation pump back on. Close open fixtures.
Before disassembling, make certain both hot and cold water sup-
plies are shut off.
Checkstop Disassembly
1. Remove bonnet with socket wrench
2. Lift out strainer screen.
3. Reassemble in reverse order.
Valve Disassembly
To Remove Thermal Actuator from Top
1. Loosen Locknut.
2. Remove bonnet and pull out overload assembly by using a stan-
dard pliers.
3. Lift out thermal actuator by using a needle nose pliers.
4. Reassemble in reverse order.
5. Temperature setting must be checked by an installer before use.
See temperature adjustment below.
To Remove The Plunger Assembly or Funnel from
Bottom
1. Remove the bottom cap.
Spring is under tension.
2. Pull out spring.
Servicing
n
IS-P-MM430 1336 EDP# 6512300 © 2013 Powers
WARNING: This product contains chemicals known to the
State of California to cause cancer and birth defects or
other reproductive harm.
For more information: www.watts.com/prop65
WARNING !
Any changes in supply condition could effect the out-
let water temperature. Check and adjust the valves
accordingly to prevent injury to the users. After com-
pleting repairs, check discharge temperature, (105°F
[41°C]). Reset if necessary. Failure to perform this
operation could result in unsafe discharge tempera-
ture, which may cause injury or death.
NOTICE
CAUTION !
What to look for if:
• The flow of water is less than desired...
a. Stop valves or supply to Hydroguard not fully open.
b. Clogged checkstop strainer screens.
c. Accumulation of lime deposits around valve seats.
d. Low supply pressures.
• The flow of water is completely shut off...
a. Stop valves or supply valves are completely closed.
b. Valves downstream from Hydroguard fully closed.
c. Loss of either hot or cold water supply pressure.
• Discharge temperature varies...
a. Very large restriction in outlet flow.
b. Very large drop in inlet pressure.
c. Very large fluctuation of hot water supply temperature.
d. Worn valve seats.
e. Minimum flow requirement not achieved.
f. Lime deposits around motor, poppets and/or seat.
Maintenance and Troubleshooting
n
NOTICE
NOTICE
USA: Phone: 1.800.669.5430 • Fax 1.847. 229.0526 • www.powerscontrols.com
Canada: Phone: 1.888.208.8927 • Fax 1.888.479.2887 • www.powerscontrols.ca
