COMPLETE REPACKING...
1. Disassemble the actuator from the valve body assembly.
2
Remove the nuts from the valve stem.
3. Remove the packing gland nut from the bonnet.
Then disassemble the bonnet from the valve body. If the
stem remains with the bonnet, on a normally open valve
only slide the stem out of the bonnet.
4. Examine the stem, replace if damaged.
5. Remove the top three packing rings, the packing spacer,
and the lower packing ring with a pointed rod or pick,
6. If a stem bearing is provided, examine it and replace if
damaged.
7. Clean packing chamber so it is free of dirt and grease.
8. To reassemble...Slide the bonnet over the stem and
screw the bonnet into the valve body.
9
If used, slide the stem bearing over the stem and into the
bonnet, make sure it is properly nested in the pocket of
the bottom of the bonnet. Use an epoxy type adhesive
(required only on ST valve) to hold the bearing in place.
10. With the valve stem held in the closed position, carefully
place a packing ring, the packing spacer, and the
remaining three packing rings over the stem in the order
shown (Figure 1). Individually tap each packing ring into
the bonnet as far as possible.
CAUTION: The splits in the packing rings must be
staggered to provide a good seal.
11. Holding the stem in the closed position, tighten the
packing gland nut sufficiently to fully compress the
packing rings into the bonnet. Loosen the packing gland
nut to readjust to “finger tight” only.
12. Pack the bonnet with recommended lubricant.
13. Reassemble actuator to valve body.
IMPORTANT: Set stem length correctly.
