26ピンカメラケーブルの接続

26-pin multi-cable connection

26 ピンケーブルでカメラアダプタとベースステーションとを接続します。

Connect both the CAMERA connectors of the Camera Adaptor and the Base Statioin with a 26-pin multi-cable.

1

CAMERA

AUDIO OUT

EXT LINE (2W I/O) EXT LINE (2W I/O)

HD/SD COMPONENT OUT

VIDEO OUT

VIDEO IN

AUX

LANC

TC OUT

EXT.

AUDIO IN

SDI IN

OUT 1

OUT 2

OUT 1

OUT 2

SDI RET IN

TC IN

RET IN

TALLY EXT LINE (4W I/O)

IN

OUT

Y

Pb

Pr

AC IN

(26-pin)

(26-pin)

ES-600

TC OUT

AUDIO IN

MADE IN JAPAN

(rear)

CAMERA connector(26-pin)

接続された 26 ピンケーブルの長さに合わせて CABLE/25/50/75/100 ケーブル切替スイッチをセットします。

Set the CABLE select switch to the appropriate position according to the length of the 26-pin multi-cable

connected to the

CAMERA connector.

2

25

50

75

100

EXT LINE (4W I/O)

INTERCOM

HEADSET

ES-600

CABLE select switch

CABLE

Multi−core Studio System NIPROS ES−300 & ES−600

ES-300

INTERCOM

HEADSET

EXT.AUDIO OUT

REMOTE

DC OUT

AUX

VIDEO IN

(VIDEO OUT/TC IN)

Pr IN

Pb IN

Y IN
