E-flite Ultimate 20-300 Assembly Manual

Note: If the control surface is tight against the main

surface, it will limit the amount of control throw the

surface can achieve.



7. Apply thin CA to the top and bottom of each

hinge. Make sure to saturate the hinges, applying

the CA to the slot in the hinge so it penetrates fully

into the hinge for the best bond between the aileron

and wing.



8. Repeat Steps 2 through 7 for the remaining aileron on

the bottom wing.



9. Repeat Steps 2 through 8 to attach the aileron to

the top wing. You should now be done with the aileron

installation.



10. Once the CA has fully cured, lightly pull on each

surface to make sure that each hinge has been fully

saturated with CA.
