3 E-flite Extra 300 32e ARF Assembly Manual
Recommended Radio Equipment
You will need a minimum 6-channel transmitter,
receiver and four servos. You can choose to purchase
a complete radio system. If you are using an
existing transmitter, just purchase the other required
equipment separately. We recommend the crystal-
free, interference-free Spektrum ™ DX6i 2.4GHz DSM ®
6-channel system. If using your own transmitter, we
recommend the JR SPORT ™ MN48 Mini servos.
If you own a Spektrum radio, just add a DSM2 ™ receiver
and four JR SPORT MN48 mini servos. We show the
installation of the AR6200 receiver in the manual.
Transmitter
SPM6600 DX6i 6-Channel Full Range w/o
Servos MD2
Or Purchase Separately
SPMAR6200 DSM2 AR6200 6-Channel
Receiver Ultralite
And
JSP20040 MN48 Mini Servo (4)
JSP98100 3-inch (76mm) Servo Extension
JSP98110 6-inch (152mm)
Servo Extension (2)
JSP98120 18-inch (457mm)
Servo Extension
JRPA215 Heavy-Duty Servo Horn (2)
Required Tools and Adhesives
Tools & Equipment
Crimping tool Side Cutters
Epoxy brushes Felt-tipped pen
Flat file Hobby knife (#11 blade)
Hobby scissors Low-tack Tape
Mixing cup Medium grit sandpaper
Mixing stick Nut Driver 7mm
Paper towel Pencil
Petrolium jelly Phillips screwdriver: #1, #2
Pin vise Pliers (2)
Rubbing alcohol Ruler
Square String
T-pins Toothpicks
Adjustable wrench
Open end or box wrench: 10mm
Ball driver or hex wrench: 3/32 inch, 1.5mm
Drill bit: 1/16-inch (1.5mm), 5/64-inch (2mm)
Adhesives
Threadlock Thin CA
Canopy glue 30-minute epoxy
Brushless Outrunner Setup
EFLM4032A Power 32 Brushless Outrunner
Motor, 770Kv
APC14070E APC 14x7E Propeller or
APC13065E APC 13x6.5E Propeller
EFLA1060 60-Amp Pro Switch-Mode BEC
Brushless ESC
THP38504SP30 3850mAh 4S 14.8V Pro Power
30C Li-Po
EFLSP225 2 1 /
4
inch Aluminum Spinner
Optional Accessories
EFLA110 Power Meter
EFLC505 Intelligent 1- to 5-Cell
Balancing Charger
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly
more volatile than alkaline or Ni-Cd/
Ni-MH batteries used in RC applications.
All manufacturer’s instructions and warnings
must be followed closely. Mishandling of
Li-Po batteries can result in fire. Always
follow the manufacturer’s instructions when
disposing of Lithium Polymer batteries.
Warning
An RC aircraft is not a toy! If misused, it can cause
serious bodily harm and damage to property. Fly
only in open areas, preferably at AMA (Academy of
Model Aeronautics) approved flying sites, following all
instructions included with your radio.
Keep loose items that can get entangled in the
propeller away from the prop, including loose clothing,
or other objects such as pencils and screwdrivers.
Especially keep your hands away from the propeller.
During the course of building your model we suggest
that you use a soft base for the building surface.
Such things as a foam stand, large piece of bedding
foam or a thick bath towel will work well and help
protect the model from damage during assembly.
This is not shown in the assembly photographs to
display the detail of the actual building of the model.
