27 E-flite Extra 300 32e ARF Assembly Manual
 15. Slide a crimp on the end of the cable outside
the fuselage. The cable then can pass through
the hole in the cable fitting then back through the
crimp. Do not use crimping pliers at this time.
 16. Repeat Steps 13 through 15 for the opposite
cable. Remove the tape from the fuselage at this
time as well.
When setting the rudder cables it is best to have the
radio system on to keep the rudder servo centered.
 17. Adjust the cable in the crimps so there is light
tension on each of the cables. Once tensioned, use
crimping pliers to secure the crimps to the cables.
Use side cutters to trim any excess wire that could
interfere with the operation of the rudder.
Check the tension of the cables periodically to make
sure they are not slack. If so, adjust the clevises on
both sides to reset the tension on the wires or you may
have difficulty keeping the rudder correctly trimmed.
 18. You may now remove the low-tack tape that is
holding the rudder straight.
 19. Now re-tension the cables to ensure the
rudder moves freely and holds center with the
radio system on.
