W100T Twin Alternating Series Softeners

5

Pre-Installation Considerations

(continued)

G. Pre Installation and Loading of Media

Systems that are 13” in diameter and larger are not loaded with

media. These systems must be loaded with media before placing

into service. To load a system follow the below steps.
1. Cap the top open end of the distributor tube with tape and

plastic sheeting to keep foreign debris from entering the

distributor tube. This cap must be secure and not come off

during media loading.

2. Place the distributor tube, screen end down, into the mineral

tank and center it in the bottom. The top of the distributor

tube should be flush with the top of the tank. If 4” x 2.5” tank

bushings are used, the distributor tube should be flush with the

top of the tank bushing.

3. Make sure the plastic and tape cap is secure to the top of the

distributor tube, place a funnel on the top of the tank and load

first the gravel (if different sizes of gravel are used load the

largest gravel first, then the smaller gravel) then the resin media

into the tank. The cap must not come off of the distributor tube

during the loading of the media.

4. Remove the plastic cap from the distributor tube. DO NOT

PULL UP ON THE DISTRIBUTOR TUBE when removing the

cap. The distributor tube top must remain flush with the top of

the tank.

5. Clean any media from the threads and top of the mineral tank.
6. Lubricate the O-rings on the bottom of the control valve

(distributor pilot O-ring and top of tank O-ring). Use non-

petroleum based silicone lubricant only.

7. Place the control valve on top of the tank. When doing this

step, seat the top of the distributor tube inside the centered

O-ring sealed port on the bottom of the valve first then press

the valve down until the tank threads come in contact with the

valve threads. This ensures that the distributor tube is properly

seated into the bottom of the control valve. Thread the valve

on to the tank clockwise. Be careful not to cross thread the

valve or over tighten it. A hand tight snug fit is appropriate for

the control valve torque. A wrench is not necessary. Do not use

thread sealant or PTFE tape on the valve base threads.

8. The system is now ready for installation. Follow the Installation

Section in the Installation, Operation and Maintenance Manual.


Do not exceed water pressure of 120 psi

(8.2 bar). Do not exceed 110°F (43.3°C).

Do not subject unit to freezing conditions.

General Installation Instructions

1. Turn off water heater(s).
2. Turn off the main water supply to the home and open an inside

faucet (cold and hot) to relieve any pressure within the plumbing

system.

3. Place the system in the desired installation location. Make

sure that the location is level and sturdy enough to support the

weight of the system once it is in operation.

4. Place the bypass valve in the bypass position.
5. Connect the cold water supply to the inlet of the water

conditioning system. While constructing the supply line, install a

master supply valve (user supplied) in the supply line and close

it.

6. Connect the feed water line to the home to the outlet of the

system.

7. Plumb the drain line to an appropriate drain abiding by all local,

city, and state codes. Use a 3/4” drain line for backwash flow

rates of 7 gpm or for drain lines of 7 gpm and less that exceed

20’ in length. Use a 1” drain line for backwash flow rates of 10

gpm and 12 gpm.

8. Connect the brine tank to the water softener control valve brine

inlet port using the factory supplied fittings and tubing. Add

enough water to the brine tank so that water covers the top of

the air check. DO NOT ADD SALT AT THIS TIME.

9. Open the user supplied feed water valve. Check for leaks and

repair as needed.

10. Allow the inside hot and cold faucet to remain open until all air

has been purged from the plumbing system. Then close the

faucet.

11. Locate Manual Regeneration Options in this manual to see

the steps to initiate an Immediate Manual Regeneration. Once

you have read that section place the system in backwash and

unplug the system from its electrical outlet once it has cycled

into the backwash position. This will stall the unit in backwash

so all air can be purged from one of the tanks.

12. Adjust the user supplied feed water valve to 1/4 open and place

the bypass valve into the service position.

13. Air will come out of the drain line until the backwashing tank is

completely purged of air. Then water will flow to drain. Allow

water to flow to drain for 15 minutes or until the water to drain

is clear of resin color throw.

14. Plug the system back into the electrical outlet and manually

cycle it through the remaining regeneration steps until it arrives

in the service position.

15. Repeat installation steps 11, 12, 13, and 14 of the General

Installation Instructions to purge the air from the second tank.

16. Check for leaks and repair as needed.
17. Installation is now complete and the system is ready for

programming and one cycle of brine tank refill so that the

correct amount of water is in the brine tank for the first

regeneration cycle. The brine tank refill must be done after

programming the system.
