22 W100T Twin Alternating Series Softeners
Drawing No. Order No. Description Quantity
1 V3470 SCREW BHC 1/4-20 X 1 SS 12
2 V3724 WASHER FLAT SS 1/4 12
3 V4005-01 T1 TRANSFER CAP ASY 1
4 V4029 O-RING 236 2
5 V4015 T1 TRANSFER SPRING 2
6 V4014 T1 TRANSFER SPRING SUPPORT 2
7 V4036 T1 ROTOR DISK ASY 2
8 V3105 O-RING 215 (DISTRIBUTOR TUBE) 1
9 V3180 O-RING 337 1
10 V4016 T1 TRANSFER SEAL 6
11 V3031 T1 BODY SFT WTR REGEN 1
12 V4023 T1 TRANSFER DRIVE SHAFT ASY 1
13 V3287 O-RING 110 2
14 V4006-01 T1 TRANSFER DRIVE CAP ASY 1
15 V4011-01 T1 TRANSFER DRIVE GEAR ASY 1
16 V4012 T1 TRANSFER DRIVE GEAR AXLE 1
17 V4013 T1 TRANSFER REDUCTION GEAR 1
18 V3264 CWS200 BYPASS REDUCTION GEARAXLE 3
19 V3110 W100T DRIVE REDUCING GEAR 12X36 3
20 V3262-01 1.5” & 2” ALT/2BY REDUCGEARCVRASY 1
21 V3592 SCREW #8-1 PHPN T-25 SS 3
22 V4049 T1 COVER ASSEMBLY 1
NOT SHOWN V4043 T1 TRANSFER MOTOR ASY 1
NOT SHOWN V3151 W100T NUT 1 QC 1
NOT SHOWN V4055* TWIN TANK METER ASY 1
NOT SHOWN V4017-01 T1 INTERCONNECT FITTING ASY 1
NOT SHOWN D1400 1191 IN/OUT HEAD 1
*
THIS WATER METER SHOULD NOT BE USED AS THE PRIMARY MONITORING DEVICE FOR CRITICAL OR
HEALTH EFFECT APPLICATIONS.
Twin Transfer (continued)
