62 PARTS AND ACCESSORIES
Rev A
Performa Parts List
*Not shown on drawing.
Code
Part
No. Description Qty. Code
Part
No. Description Qty.
1 1035807 Valve Assembly w/o Flow Controls 1 1035735 “K” Injector (High Efficiency) - Pink
2 1235338 Top Plate, 268/700 Series Valves 1 (12-inch tank)
3 1235339 Valve Disc Spring, One Piece, Performa 1 1035736 “L” Injector (High Efficiency) - Orange
Valve (13 & 14-inch tanks)
4 1236246 Cover, Valve, 255/Performa Logix Series 1 1032978 Plugged Injector for 263 Filter
Controller 1032985 Plugged Injector Cap
5 Performa Logix Camshafts 1 10A 1000222 Regenerant Refill Controller, No Bal, 0.33 gpm 1
1235352 Cam, 263-268/700 Series Valve, STD, 10B 1243510 Regenerant Refill Controller
Black 11 1030502 Ball, Refill Flow Control
6 Drain Control Assembly: 1 * 1030334 Plugged Refill Flow Control - for 263 Valve
1000209 No. 7 (1.3 gpm; 4.9 Lpm) 12 1002449 Drain Fitting Elbow (3/4-inch hose barbed) 1
1000210 No. 8 (1.7 gpm; 6.4 Lpm) 13 1010428 O-Ring 1
1000211 No. 9 (2.2 gpm; 8.3 Lpm) 14 1000269 Injector Cap with O-Ring 1
1000212 No. 10 (2.7 gpm; 10.2 Lpm) 15 1035622 Tank Ring 1
1000213 No. 12 (3.9 gpm; 14.76 Lpm) * 1041174 Valve Disc Kit: Standard
1000214 No. 13 (4.5 gpm; 17 Lpm) 16 Plumbing Adapter Kits: 1
1000215 No. 14 (5.3 gpm; 20 Lpm) 1001606 3/4-inch Copper Tube Adapter Kit
1239760 Blending Valve Kit 900/700 Series Top Plate 1001670 1-inch Copper Tube Adapter Kit
* Drain Line Flow Control (External) 1 1001608 22-mm Copper Tube Adapter Kit
1030355 Drain Line Flow Control, 5 gpm (19 Lpm) 1001613 3/4-inch CPVC Tube Adapter Kit
1030356 Drain Line Flow Control, 6 gpm (22.5 Lpm) 1001614 1-inch CPVC Tube Adapter Kit
1030357 Drain Line Flow Control, 7 gpm (26.5 Lpm) 1001615 25-mm CPVC Tube Adapter Kit
1030358 Drain Line Flow Control, 8 gpm (30 Lpm) 1001769 3/4-inch NPT Plastic Pipe Adapter Kit
1030359 Drain Line Flow Control, 9 gpm (34 Lpm) 1001603 1-inch NPT Plastic Pipe Adapter Kit
1030360 Drain Line Flow Control, 10 gpm (38 Lpm) 1001604 3/4-inch BSPT Plastic Pipe Adapter Kit
7 1235269 Motor/Optical Cable Assembly, 700 Series 1 1001605 1-inch BSPT Plastic Pipe Adapter Kit
Controller 1001611 3/4-inch BSPT Brass Pipe Adapter Kit
8 1000226 Screen/Cap Assembly w/ O-Ring 1 1001610 1-inch NPT Brass Pipe Adapter Kit
9 Injector (High Efficiency) Options 1001612 1-inch BSPT Brass Pipe Adapter Kit
1035730 “E” Injector (HIgh Efficiency) - Yellow 17 1235373 Module, Sensor, Photo Interrupter 1
(6-inch tank) 18 1235361 Motor w/Spacer & Pinion, 700 Series Controller, 1
1035731 “F” Injector (High Efficiency) - Peach 12 V, 50/60 Hz 1
(7-inch tank) 19 1001986 13/16 inch Rubber Insert (Optional) 1
1035732 “G” Injector (High Efficiency) - Tan 20 1235446 Turbine Cable 1
(8-inch tank) 21 1010154 Tank O-Ring 1
1035733 “H” Injector (High Efficiency) - Lt Purple * 1033444 Internal Turbine Meter
(9-inch tank) * 1233187 Motor Locking Pin
1035734 “J” Injector (High Efficiency) - Lt Blue * 1268102 No Salt Detector/Refill Control
(10-inch tank) * 1033444 Turbine Assembly
* 1041174 Valve Disc Kit, Standard
* 1239979 Cable Harness, Remote Regen 740F
* 1239711 Switch Kit, Front Mount, 0.1 amp
* 1239752 Switch Kit, Front Mount 5 amp
* 1239753 Switch Kit, Top Plate Mount, 0.1 amp
* 1239754 Switch Kit, Top Plate Mount, 5 amp
