PROGRAMMING THE 700 FOR 5-CYCLE FILTER APPLICATIONS 43
Rev A
Accessing History Values
The Logix control features a review level that displays the operation
history of the system. This is a great troubleshooting tool for the control
valve.
To access history values, press and hold SET and DOWN for five seconds
to view the "H" levels.
History Values
Resetting the Logix Control
To reset the control:
1. Press and hold SET and DOWN simultaneously for 5 seconds.
2. H0 and the system’s set resin volume (or “F” mode) will be displayed.
3. If a history value other the “H0” is displayed, use the UP button to
scroll through the settings until “H0” is displayed.
4. To reset the control, press and hold SET for 5 seconds.
5. The control will be reset to an unprogrammed state.
6. Go to “Initial Set-up” section to reprogram control.
Description Range
H0 Resin volume initial setting value Cubic feet or liters
H1 Days since last regeneration 0 – 255
H2 Current flow rate 0 – 47 GPM or 0 – 177 LPM
H3 Water used today in gallons/m 3 since Time of
Regeneration
0 – 65536 gallons or 0 – 6553.6 m 3
H4 Water used since last regeneration in gallons/m 3 0 – 65536 gallons or 0 – 6553.6 m 3
H5 Total water used since reset in 100s 0 – 65536 gallons or 0 – 6553.6 m 3
H6 Total water used since reset in 1,000,000
0 – 65536 gallons or 0 – 6553.6 m 3
H7
Average usage for Sunday in gallons or m
3
0 – 65536 gallons or 0 – 6553.6 m
3
H8 Average usage for Monday in gallons or m 3 0 – 65536 gallons or 0 – 6553.6 m 3
H9
Average usage for Tuesday in gallons or m 3 0 – 65536 gallons or 0 – 6553.6 m 3
H10
Average usage for Wednesday in gallons or m
3
0 – 65536 gallons or 0 – 6553.6 m
3
H11 Average usage for Thursday in gallons or m 3 0 – 65536 gallons or 0 – 6553.6 m 3
H12
Average usage for Friday in gallons or m 3 0 – 65536 gallons or 0 – 6553.6 m 3
H13
Average usage for Saturday in gallons or m
3
0 – 65536 gallons or 0 – 6553.6 m
3
WARNING: Resetting the control will delete all information stored in its
memory, except time and day. This will require you to reprogram the
control completely from the initial power-up mode.
