60

PARTS AND ACCESSORIES

Rev A

255 Valve Parts List (Continued)

*Not Shown

Code

Part

No.

Description Qty. Code

Part

No.

Description

Qty.

*

Piping Boss

Tube Adapter Kits

Piping Boss Kit (includes hardware):

*

1001606

3/4-inch Copper Tube Adapter Kit

1

1040277

3/4-inch NPT, Brass 3/8-inch NPT Drain

*

1001670

1-inch Copper Tube Adapter Kit

1

1040278

1-inch NPT, Brass 1/2-inch NPT Drain

*

1001608

22-mm Copper Tube Adapter Kit

1

1040281

3/4-inch BSPT, Brass 3/8-inch BSPT

*

1001613

3/4-inch CPVC Tube Adapter Kit

1

Drain

*

1001614

1-inch CPVC Tube Adapter Kit

1

1040282

1-inch BSPT, Brass 1/2-inch BSPT Drain

*

1001615

25-mm CPVC Tube Adapter Kit

1

1040279

3/4-inch NPT, Noryl 1/2-inch NPT Drain

*

1001769

3/4-inch NPT Plastic Pipe Adapter Kit

1

1040280

1-inch NPT, Noryl 1/2-inch NPT Drain

*

1001603

1-inch NPT Plastic Pipe Adapter Kit

1

1040283

3/4-inch BSPT, Noryl 1/2-inch BSPT

*

1001604

3/4-inch BSPT Plastic Pipe Adapter Kit

1

Drain

*

1001605

1-inch BSPT Plastic Pipe Adapter Kit

1

1040284

1-inch BSPT, Noryl 1/2-inch BSPT Drain

*

1001611

3/4-inch BSPT Brass Pipe Adapter Kit

1

*

1040339

Piping Boss Installation Kit

1

*

1001610

1-inch NPT Brass Pipe Adapter Kit

1

*

Meter Adapter

*

1001612

1-inch BSPT Brass Pipe Adapter Kit

1

1032350

Kit, Meter Adapter

1

1032351

Meter Install Kit

1

*

Bypass Valve

1040769

Bypass Body Assembly with Install Kit

1

1040524

Bypass Installation Kit

1
