Connection to the guarded machine – Banner DUO-TOUCH SG Two-Hand Control Safety Modules User Manual
Page 8
STB2
Brown
Blue
MPCE2 MPCE1
White
Yellow
Black
White
Yellow
Black
A2
Y1
(1)
Y2
24V ac/dc
0V ac/dc
S12
A1
S11
S13
S22
S21
S23
K1
K2
13
23
14
24
+ –
STB1
AT-FM-10K
+ –
L1/+V dc
L2/–V dc
MPCE
1
*
*
Machine
Control
Circuit
MPCE
2
Figure 4. Connection to two STB Touch Buttons with contact
outputs
Logic
STB2
Brown
MPCE2
(1)
MPCE1
White
Black
White
Black
A2
A1
Y1
Y2
24V dc
0V dc
S12
S11
S13
S22
S21
S23
K1
K2
13
23
14
24
+ –
STB1
AT-FM-10K
+ –
Machine
Control
Circuit
L1/+V dc
L2/–V dc
MPCE
1
MPCE
2
*
*
Logic
Blue
Figure 5. Connection to two STB Touch Buttons with PNP
(sourcing) outputs
WARNING: Interfacing Safety Outputs
NEVER wire or interface an intermediate device (for example, PLC, PES, PC) that can fail in
such a manner that there is a loss of the safety stop command to the MPCEs.
To do so could result in serious bodily injury or death.
SW1
MPCE2
MPCE1
A2
Y1
(1)
Y2
24V ac/dc
0V ac/dc
S12
A1
S11
S13
S22
S21
S23
K1
K2
13
23
14
24
SW2
AT-FM-10K
Machine
Control
Circuit
L1/+V dc
L2/–V dc
MPCE
1
MPCE
2
*
*
* Arc Suppressor – See Warning
(1) See Warning about Interfacing Safety Outputs
Figure 6. Connection to two mechanical push buttons with
contact outputs
WARNING: Wiring of Arc Sup-
pressors
If arc suppressors are used,
they MUST be installed as
shown across the actuator coil of
the stop control elements (MSCs
or MPCEs). NEVER install sup-
pressors directly across the
output contacts of the Safety
Device or Module. It is possible
for suppressors to fail as a short
circuit. If installed directly across
the output contacts, a short-
circuited suppressor will create
an unsafe condition which
could result in serious injury or
death.
Connection to the Guarded Machine
WARNING: Interfacing MSCs
NEVER wire an intermediate device(s) (for example, PLC, PES, PC) between the Safety Module outputs
and the Master Stop Control Element it switches in such a manner that in the event of a failure there is a
AT-FM-10K Two-Hand Control Module
8
www.bannerengineering.com - tel: 763-544-3164
P/N 64137 Rev. G
