Viewing Results
Display Options
Next Pass
Display only the next passing inspection.
Next Fail
Display only the next failing inspection.
Next
Continuously display inspections.
None
Don’t display any inspections.
Click + to
expand and –
to contract
category
Click on
Tool name
to show
the ROI
Passing
Tool
Failing
Tool
Product
Select
#3 (Pin 16)
Product
Select
#2 (Pin 17)
Product
Select
#1 (Pin 18)
Product
Select
#0 (Pin 19)
Inspection
#
OFF
OFF
OFF
ON
1
OFF
OFF
ON
OFF
2
OFF
OFF
ON
ON
3
OFF
ON
OFF
OFF
4
OFF
ON
OFF
ON
5
OFF
ON
ON
OFF
6
OFF
ON
ON
ON
7
ON
OFF
OFF
OFF
8
ON
OFF
OFF
ON
9
ON
OFF
ON
OFF
10
ON
OFF
ON
ON
11
ON
ON
OFF
OFF
12
Select an inspection to run, and view the results of the inspection.
To select an inspection, (in the Select tab) enable Software Override and
select the inspection file from the list of stored inspections on the camera.
Alternate method: Use Hardware Input to select an inspection via discrete
inputs to the controller.
The following table shows which inputs to activate to select an inspection.
4.
To begin inspecting, click the Start button in the Run screen.
TIPS
TIPS
When using the
Hardware input,
pulse the Product
Change input to
initiate an
inspection change.
