page 13
system
specifications
system
specifications
Camera
Model Number PPCAM
Part Number 62568
Mechanical
Construction: Black anodized aluminum
Dimensions: 32 x 30 x 78.2 mm (1.26" x 1.18" x 3.08")
Weight: approx. 0.09 kg (0.2 lbs)
Environmental Rating: IEC IP20; NEMA 1
Operating Temperature: 0° to +50° C (+32° to +122° F)
Maximum Relative Humidity: 90%, non-condensing
Acquisition
Frames per Second: 30 max.
Image Size: 640 x 480 pixels
Levels of Gray Scale: 256
Imager
4.8 x 3.6 mm, 6 mm diagonal (1/3" CCD)
Pixel Size: 7.4 x 7.4 microns
Interface LVDS
Max. Cable
Length
7 m (23')
Exposure Time 0.01 ms to 3600 ms
Lens Mount C-mount
