page 3
components/
connections
components/
connections
Error
Model PPCTL
Controller
Fail
Pass
Power
Ready
Trigger
CHASSIS GND
20
10-3 0V dc
dc C OMMO
N
TRIGGER IN STROBE OUT
TX RT S RX CT S I/O 1 I/O 2 I/O 3 I/O 4 I/O 5
PRODUCT
S EL 0
19
PRODUCT
S EL 1
18
PRODU
CT S EL 2
17 PRODUCT
S EL 3
16 PRODUCT
CHANG
E
15
I/O 6
14 13 12 10 11 09 08 07 06 05 04 03 02 01
Model PPCAM
Camera
Camera
Ethernet PC Serial
Video
TIPS TIPS
The trigger device
can be any
10-30V dc
photoelectric
sensor, or a
device with a
similar output.
10-30V dcdc C
OMMON
TRIGGER
IN
STR
OB
E OUT TX RT S RX CTS I/O 1 I/O 2 I/O
3
I/O
4
I/O 5
PRO
DUC
15
I/O 6
14 13 12 10 11 09 08 07 06 05 04 03 02 01
+V
–V
Trigger
Device
Additional Connections
(Pins 4 - 20)
Pin 1 Pin 2 Pin 3
step 1 step 1
step 2 step 2
step 3 step 3
Cable Connections
1.Thread the c-mount lens onto the camera
(PPCAM).
2.Connect the camera cable (PPC..) to the
camera (PPCAM) and controller (PPCTL).
3.Connect the controller to a Windows ® PC
using either an ethernet cable or a serial
cable (DB9D..). Use crossover ethernet
cable (STPX..) for a direct connection,
and a straight ethernet cable (STP..) for
network connection.
4.Optional: Connect an NTSC video monitor
using a BNC cable.
Electrical Connections
Connect the following to the controller’s
terminal block
• +V to Pin 1 (10-30V dc)
• –V to Pin 2 (dc common)
• Trigger device to Pin 3 (Trigger In)
• Additional connections (Pin 4 - Pin 20)
Lighting
Install the dedicated light source, according
to the instructions included with the light
source.
PPCAM
Camera
to
PC
to
Monitor
to PC (Crossover)
or Network (Straight)
STPX..
Ethernet
Connection
PPC..
Camera
Cable
Video
Connection
(Optional)
DB9D..
Serial
Connection
PPCTL
Controller
