Test Power Supply
Sensor Models: P4
Lighting Variable
Power Supplies*
Lighting Power Supply
Extension Cables*
Additional Literature
More information online at
Model
Input
Input Cord
Outputs
Output Cable
Used With
Data Sheet
PS2V-12
100-140V ac
60 Hz
North America
(NEMA 5-15)
2-channels
6-12V dc
1.8 m Terminated with
9-pin D-sub connector
(female pins)
Continuous
LED Lights
PS2V-12E
200-250V ac
50 Hz
Cont. Europe
(Schuko CEE 7)
2 A max.
per channel
Model
Length
Input Cord
Used With
DB906
1.8 m
Cable powers one continuous light (one end male pins and one end
female; both ends terminated with 9-pin D-sub connector)
Continuous
LED Lights
DB910
3.0 m
DB9Y
1.8 m
Cable powers two continuous lights with one supply (9 m trunk
with male connector and 9 m branches with female connector; ends
terminated with 9-pin D-sub connector)
Continuous
LED Lights
DB906S
1.8 m
Cable powers one strobed light (one end male pins and one end
female; both ends terminated with 9-pin D-sub connector)
Strobed
LED Lights
DB910S
3.0 m
DB9YS
1.8 m
Cable powers one strobed light (9 m trunk with male connector and
9 m branches with female connector; ends terminated with 9-pin
D-sub connector)
Strobed
LED Lights
* Available Q2 2007
Model
Input
Input
Trigger Option
Data Sheet
P4D1
100-240V ac
North America (AC plug)
• 24V dc NPN Sensor
• Continuous pulse
• Single pulse
—
Note: 1 amp power supply used to power P4 sensor and lighting for proving an application without integation into a control panel.
Description
Used With
Data Sheet
PresencePLUS Software on CD-ROM—Available for Download Online
Pro, P4
Pro Sensors Manual
Pro
Pro COLOR Sensors Manual*
Pro COLOR
Pro & Pro COLOR Quick Start Guide
Pro
P4 OMNI & OMNI 1.3 Sensors Manual
P4 OMNI, P4 OMNI 1.3
P4 COLOR Sensor Manual*
P4 COLOR
P4 GEO and GEO 1.3 Sensors Manual
P4 GEO, P4 GEO 1.3
P4 AREA & AREA 1.3 Sensors Manual
P4 AREA, P4 AREA 1.3
P4 EDGE and EDGE 1.3 Sensors Manual
P4 EDGE, P4 EDGE 1.3
P4 BCR & BCR 1.3
P4 BCR, P4 BCR 1.3
P4 Quickstart Guide
P4
* These products are not stocked and are non-returnable.
