PresencePLUS ® P4 Specifications
PresencePLUS ® P4 Specifications
Supply Voltage and Current
10 to 30V dc (24V dc ±10% if the sensor powers a light source)
OMNI, OMNI with BCR & BCR: less than 650 mA (exclusive of lights and I/O load)
AREA, GEO & EDGE: less than 500 mA (exclusive of lights and I/O load)
OMNI 1.3, OMNI 1.3 with BCR, COLOR OMNI, COLOR OMNI with BCR, AREA 1.3, GEO 1.3, EDGE 1.3 &
BCR 1.3: less than 550 mA (exclusive of lights and I/O load)
Memory
Storage: BCR—8 MB Inspection (jobs): 400 max.
AREA, GEO, EDGE—8 MB Inspection (jobs): 500 max.
All others—32 MB Inspection (jobs): 999 max.
Input/Output Configuration NPN (sinking) or PNP (sourcing) software selectable
Output Rating
150 mA max. each output
OFF-state leakage current: less than 100 µA ON-state saturation voltage: NPN—less than 1V @ 150 mA max.
PNP—greater than V+ -2V
Bicolor Status Indicators
PASS/FAIL: Green ON steady—PASS Red ON steady—FAIL
POWER/ERROR: Green ON steady—POWER Red ON steady—ERROR
READY/TRIGGER: Green ON steady—READY Yellow ON steady—TRIGGER
Display Options PC or NTSC video (uses 9 m max. BNC cable)
Discrete I/O
1 Trigger IN
1 Strobe OUT
4 Programmable I/O
1 Product Change IN
1 Remote TEACH IN
Communications
1 RJ-45 10/100 Ethernet connection for running PresencePLUS P4 software and/or output inspection results
RS-232 flying leads
Imager Resolution
OMNI, OMNI with BCR & BCR: 640 x 480 pixels
OMNI 1.3, OMNI 1.3 with BCR, AREA 1.3, GEO 1.3, EDGE 1.3 & BCR 1.3: 1280 x 1024 pixels
AREA, GEO & EDGE: 128 x 100 pixels
COLOR OMNI & COLOR OMNI with BCR: 752 x 480 pixels
Pixel Size
OMNI, OMNI with BCR & BCR: 7.4 x 7.4 µm
OMNI 1.3, OMNI 1.3 with BCR, AREA 1.3, GEO 1.3, EDGE 1.3 & BCR 1.3: 6.7 x 6.7 µm
AREA, GEO & EDGE: 20 x 20 µm
COLOR OMNI & COLOR OMNI 1.3: 6.0 x 6.0 µm
Imager Size
OMNI, OMNI with BCR & BCR: 4.8 x 3.6 mm, 6 mm diagonal (1/3 inch CCD)
OMNI 1.3, OMNI 1.3 with BCR, AREA 1.3, GEO 1.3, EDGE 1.3 & BCR 1.3: 8.6 x 6.9 mm, 11 mm diagonal (2/3 inch CMOS)
AREA, GEO & EDGE: 2.6 x 2.0 mm, 3.3 mm diagonal (1/5 inch CMOS)
COLOR OMNI & COLOR OMNI with BCR: 4.5 x 2.9 mm, 5.4 mm diagonal (1/3 inch CMOS)
Levels of Gray Scale
or Color
OMNI, OMNI with BCR, OMNI 1.3, OMNI 1.3 with BCR, AREA, AREA 1.3, GEO, GEO 1.3, EDGE , EDGE 1.3,
BCR & BCR 1.3: 256 Grayscale
COLOR OMNI & COLOR OMNI with BCR: 256 Red, Green and Blue
Exposure Time
OMNI, OMNI with BCR & BCR: 0.1 to 2830 milliseconds
OMNI 1.3, OMNI 1.3 with BCR, AREA 1.3, GEO 1.3, EDGE 1.3 & BCR 1.3: 0.1 to 1670 milliseconds
AREA, GEO & EDGE: 0.1 to 20.47 milliseconds
COLOR OMNI & COLOR OMNI with BCR: 0.1 to 1000 milliseconds
Acquisition
OMNI, OMNI with BCR & BCR: 48 frames per second max.
AREA, GEO & EDGE: 500 frames per second max.
OMNI 1.3, OMNI 1.3 with BCR, AREA 1.3, GEO 1.3, EDGE 1.3 & BCR 1.3: 27 frames per second max.
COLOR OMNI & COLOR OMNI with BCR: 17 frames per second max.
Lens Mount Standard C-mount (1 inch—32 UN)
Construction Black anodized aluminum housing, glass lens
Weight Approx. 0.29 kg
Environmental Rating IEC IP20; NEMA 1
Operating Temperature 0° to +50° C
Relative Humidity 90% (non-condensing)
