PresencePLUS ® Backlights
• Determines the shape and size of target objects
• Provides the most robust lighting for measuring and gauging
• Highlights through-holes in target objects
Illumination Area † Model Description Connection* Data Sheet
70 x 70 mm
LEDRB70X70W
Red
2 m 115349
LEDRB70X70M
2 m Threaded
3-pin Pico pigtail QD
116947
LEDIB70X70W
Infrared
2 m 115349
LEDIB70X70M
2 m Threaded
3-pin Pico pigtail QD
116947
85 x 220 mm
LEDRB85X220W
Red
2 m 115349
LEDRB85X220M
2 m Threaded
3-pin Pico pigtail QD
116947
LEDIB85X220W
Infrared
2 m 115349
LEDIB85X220M
2 m Threaded
3-pin Pico pigtail QD
116947
* For 9 m cable, add suffix W/30 to the 2 m model number (example, LEDRB70X70W W/30). QD models can be
connected directly to P4 sensors; splitter cables available for powering two lights (see page 45).
† For replacement windows and diffusers (see page 38).
LED Backlights
Voltage: 24V dc
Specialty
LED Backlights
Voltage: 12V dc
Illumination Area Model Description Connection* Data Sheet
50 x 50 mm
LEDRB50X50N Red diffused
1.8 m with 9-pin
D-sub connector
67426
LEDWB50X50N White diffused
LEDBB50X50N Blue diffused
LEDIB50X50N Infrared diffused
75 x 75 mm
LEDRB75X75N Red diffused
67427
LEDWB75X75N White diffused
LEDBB75X75N Blue diffused
LEDIB75X75N Infrared diffused
100 x 100 mm
LEDRB100X100N Red diffused
67428
LEDWB100X100N White diffused
LEDBB100X100N Blue diffused
LEDIB100X100N Infrared diffused
50 x 200 mm
LEDRB50X200N Red diffused 67429
LEDRB50X200N-H Red diffused, high output
67430
LEDRB50X200N-NH Red non-diffused, high output
100 x 200 mm
LEDRB100X200N Red diffused
67431
LEDIB100X200N Infrared diffused
33
More information online at bannerengineering.com
*Specialty lights are not stocked and are non-returnable; they require an external power supply (see page 46).
