Software and Tools
PresencePLUS: A comprehensive Suite
of Inspection and Analysis tools.
LOCATION TOOLS
compensatefortranslationaland
rotationalmovement.
Locate Determines translation and rotation
by detecting relative movement of edges
Pattern Find Determines translation and rotation
by detecting relative movement of a pattern
GEO Find Determines translation and rotation
movement of a part up to 360° by detecting
relative movement of a pattern
VISION TOOLS
analyzetheimage.
Color Match Inspects for matching hue
and intensity
Average Gray Scale Determines the gray scale
intensity value of an area
Blob Determines the presence, connectivity, size
and location of selected features
Edge Determines the presence, number, classification
and location of edges
Object Determines the presence, number,
classification, size and location of objects
Pattern Count Determines the presence, number
and location of pattern(s)
GEO Count Detects the presence and location of a
target pattern in any orientation
Bar Code Finds, decodes and grades advanced 2D
and 1D linear bar codes
ANALySIS TOOLS
measureandevaluatetheresults
ofthevisiontools.
Measure Measures distance and angles between
two prescribed points or lines
Math Performs arithmetic functions on any tool
or constant
Test Evaluates results of selected vision and analysis
tools to determine whether an inspection passes or
fails; performs logical operations; and activates outputs
Communication Sends image or results of selected
location, vision and analysis tools over the Ethernet
or RS-232 serial communication ports to industrial
Ethernet or PC networks
Powerful Inspection tools.
one Advanced Software Platform.
Fulfilling the capabilities of powerful PresencePLUS® vision
sensor hardware requires an equally advanced software solution.
One that operates seamlessly across all Banner vision products.
One that provides a common, intuitive graphical interface. One
so advanced, it can literally teach itself your vision challenge.
Banner’s versatile PresencePLUS software does just that.
Now configuring sophisticated vision applications is faster and
easier than ever before, while common applications are virtually
plug-and-play.
Features:
• Seamless functionality across the entire Pro and P4 vision
sensor series.
• Remote TEACH input similar to a photoelectric sensor
self-learns the inspection tolerances of your application.
• Easy, menu-driven, point-and-click interface on a PC.
• Simple push-button inspection changeovers.
• Live video display without a PC.
• ActiveX utilities for exporting inspections, images and results.
• Direct connectivity to EtherNet/IP and Modbus TCP
industrial networks.
• In nine languages including English, Simplified Chinese,
Traditional Chinese, French, German, Japanese, Portuguese
and Spanish with translated text, buttons, commands and
icons in the respective language.
• Operates on Microsoft Windows® operating systems.
• Free web download or CD-ROM; includes all Banner vision
sensor manuals, troubleshooting guides, and lens and
lighting selection guides.
• Free firmware and software upgrades.
PresencePLUS Software operation
3-point click-and-go Intuitive, wizard-like graphics walk the oper-
ator through adjusting the sensor position, selecting the features
to inspect, operating the sensor and monitoring its outputs.
Setup Dynamically view the sensor image, adjust the lighting
position and intensity, and then focus the lens to maximize contrast
between target features and the background.
Tools Highlight the features to inspect while selecting tools and
filters to maximize robust operation. Choose criteria and margins
for good or failed outputs. Select data or images to communicate
through the Ethernet or serial ports.
Run Operate inspections and sensor outputs while viewing
images or exploring the detailed, comprehensive inspection
results. Select the inspection to run. Log any inspection to archive
its images and results.
COMMON
User Interface
across all Banner Vision products
