PresencePLUS ® P4 Hookups & Dimensions
27
More information online at bannerengineering.com
136.1 mm
34.3 mm
66.8 mm
66.8 mm
124.5 mm
34.4 mm
136.1 mm
34.3 mm
66.8 mm
66.8 mm
124.5 mm
34.4 mm
NPN Outputs with NPN Inputs † PNP Outputs with PNP Inputs †
10-30V dc
RS-232
Transmit
Trigger IN
I/O 4
I/O 3
I/O 2
I/O 1
RS-232
Receive
RS-232
Ground
Chassis
Ground
† Inputs can be either NPN or PNP.
* Can be independently configured as an output or input.
PNP Outputs with PNP Inputs †
–
+
12
11
5*
Shield
7*
6*
8*
4
3
2
10
9
1
Load
Load
Load
Load
Product
Change IN
Remote
TEACH IN
2
11
3 6
7
12
8
9
10
4 5
1
Key
1 = Yellow
2 = Gray
3 = Orange
4 = Pink
5 = Black*
6 = Red*
7 = White*
8 = Light Blue*
9 = Purple
10 = Green
11 = Blue
12 = Brown
Shield = Bare Metal
12-Pin QD
† Inputs can be either NPN or PNP.
* Can be independently configured as an output or input.
In-Line Sensor Models
(Shown with lens—sold separately)
Right-Angle Sensor Models
(Shown with lens—sold separately)
3-pin Pico QD Banner
Vision Light
BNC Coaxial
Video Cordset
12-pin QD Cable
RJ45 Ethernet
Cordset
10-30V dc
RS-232
Transmit
RS-232
Receive
RS-232
Ground
Chassis
Ground
† Inputs can be either NPN or PNP.
* Can be independently configured as an output or input.
NPN Output with NPN Inputs †
–
+
11
12
5*
Shield
7*
6*
8*
4
3
2
10
9
1
Load
Load
Load
Load
Trigger IN
Product
Change IN
Remote
TEACH IN
I/O 4
I/O 3
I/O 2
I/O 1
P4 Hookup Diagrams
Connection Points Dimension Drawings
Detailed
Dimensions
