Splitter Cables
3-Pin Pico Splitters
Light Models: Ring Lights, Area Lights,
Spot Lights and
Backlights
4-Pin Euro Splitters
Light Models: Sealed Linear Array
Lights, EZ-LIGHT
45
More information online at bannerengineering.com
Communications Cordsets
RJ45 Ethernet
Sensor Models: Pro, P4
DB9 Serial
Sensor Models: Pro
Light Cables & Cordsets
3-Pin Pico QD
Light Models: Sealed Ring Lights
4-Pin Euro QD
Light Models: Sealed Linear
Array Lights, EZ-LIGHT
End View Model Branches Trunks
Female Male
1 = Brown
3 = Blue
4 = Black
CSB-M831M831
3-Pin Pico QD
2 x 0.2 m Female
0.2 m Male
Dimensions
Female Male
1 = Brown
2 = White
3 = Blue
4 = Black
CSB-M1241M1241
4-Pin Euro QD
2 x 0.3 m Female
0.3 m Male
CSB-UNT425M1241 8 m unterminated
Dimensions
4
1 3
4-Pin Euro
2
3
4
1
4-Pin Male Euro
2
3
4
1
48.5 mm
M12 x 1
ø 15 mm 18 mm
18 mm
(Trunk)
(Branches) 25 mm
42 mm M12 x 1
ø 15 mm
ø 9.6 mm
M8 x 1
41.2 mm
ø 9 mm
M8 x 1
34.7 mm
16.8 mm
22.8 mm
25 mm
(Trunk)
(Branches)
End View Model Description Length Dimensions
Male
STP07 Cat5e Shielded
2.1 m
RJ45
STPX07
Cat5e Crossover
Shielded
STP25 Cat5e Shielded
7.3 m
STPX25
Cat5e Crossover
Shielded
STPX75 Cat5e Shielded 23 m
Male DB9
Female DB9
DB9P06
Male DB9/
Female DB9
2 m
DB9 Male
DB9 Female
DB9P15 5 m
DB9P30 9 m
40.5 mm
11.6 mm
14.3 mm
31 mm
18 mm
47.5 mm
31 mm
16.4 mm
47.5 mm
End View Model Description Length Dimensions
Female
1 = Brown
3 = Blue
4 = Black
PKG3M-4
Female Straight
4 m
Straight
PKG3M-7 7 m
PKG3M-10 10 m
Female
1 = Brown
2 = White
3 = Blue
4 = Black
MQDC-406
Female Straight
2 m
Straight
MQDC-415 5 m
MQDC-430 9 m
34.7 mm
ø 9.6 mm
M8 x 1
M12 x 1
ø 15 mm
44 mm
max.
4
3 1
2
3
4
1
