4.2 Care and maintenance

Metrohm 838 Advanced Sample Processor, Service, maintenance, faults

65

4.2.3 Replacing the dialysis membrane

It may be necessary to replace the dialysis membrane in the following

cases:

• Reduced yield in dialysis
• Dried-out membrane or membrane damage as the result of

deposits or bacterial growth

• Irremediable blockage of the sample channel (sample is no

longer able to be pumped through the dialysis cell)

Proceed as follows in order to exchange the membrane (see also

3.3.7):

1 Detaching the dialysis cell

Unscrew the four inlet resp. outlet capillaries from the dialysis

cell 37 and remove the cell from the cell holder.

Using the 6.2621.070 Allen key, fully undo the 5 screws 42

and separate the lower section 41 from the upper section 38

Remove the old dialysis membrane 40.

2 Cleaning the dialysis cell, fitting the dialysis mem-

brane and fitting the cell back on

See Chapter 3.3.7 Fitting the dialysis cell.

3 Connecting the dialysis cell

See Chapter 3.3.12 Connecting the dialysis cell.

4 Conditioning the dialysis membrane

See also Chapter 3.3.12.

Immerse the two aspiratory tubings 68 and 72 (see Figure

24) into the acceptor solution (degassed ultra-pure water).

Switch on the peristaltic pump in «IC Net».

Rinse the dialysis system for approx. 20 minutes with ultra-

pure water. Check whether solution is emerging uniformly at

the two inlet capillaries into the waste vessel.

Check all tubings from the supply vessels through the tubing

cartridges and the dialysis cell as far as the waste vessels for

escaping fluid. If fluid is escaping, at any point, the corre-

sponding connection must be tightened or replaced.

If air bubbles remain in the dialysis cell, unscrew the PEEK

capillary 76 (acceptor solution) and PTFE capillary 73 (sam-

ple) from the outlets 44 resp. 47 of the dialysis cell and wait

until the air bubbles have disappeared. Then screw the tub-

ings back onto the dialysis cell.

Switch off the peristaltic pump.
