3.5 Connection to Metrohm IC systems
54 Metrohm 838 Advanced Sample Processor, Installation
838-specific settings in the «IC Net 2.3» program
Program for the 838 Advanced Sample Processor:
001 Move Sample
002 Lift work
003 Pump 240 s
− Move needle to sample position
− Move lift with needle to working height
− Fill sample loop with sample
Time program for 761
Switchover of the injection valve
is programmed in the time pro-
gram of the 761 Compact IC.
The times may need to be adap-
ted for the application.
The functions of the 838 Advanced Sample Processor may be triggered
time-controlled via remote connection for more complex sample prepa-
ration steps. A simple example is shown below.
838
761
PC PC
Figure 40 Interconnection with compact systems via remote connection (PC-controlled)
6.2141.190 6.2134.100 6.2134.100
