6 838 Advanced Sample Processor, Introduction
1.3.2 Rear panel
Swing
Head
Ext.
Pump 2
Ext.
Pump 1
W A R N IN G - F ir e H a z a r d -
w i th th e sa m e t yp e an d ra tin g o f fu s e
F or c o n tin u e d p ro te c tio n r ep la c e o n ly
M a d e by M e tro h m
H e ris a u S w itz e rl a n d
S : 1 1 5 V A U : 1 0 0 - 2 4 0 V f: 5 0 - 60 H z
R S 23 2
M SB 1
M SB 3 M SB 2 P ow e r K e y bo a rd
R e m o te
1. 83 8. 00 10
01 10 7
Figure 4 Rear panel
12 Pump connections M8 (external)
for 772 or 823 pump models
15 Connection panel
13 Stirrer connection
for 802 rod stirrer or
741 magnetic stirrer
a Warning:
Biohazard
See Chapter 2.3 Personal protection
14 Connection socket for the
786 Swing Head
12
13 14
15
a
