Z15-G: 142mm ×76mm
GCU BEC Output
10A@12V
GCU Wireless Video Transmission Power
1A @12V
GCU Weight
63g
GCU Dimensions
64.2 mm ×34.1mm ×19.5mm
Working Performance
Load Weight (Reference Value)
336g(@
Sony NEX-5N with Lens and Battery
)
417g(@
Sony NEX-7 with Lens and Battery
)
344g(@
Sony NEX-5R with Lens and Battery
)
489g(
@
Panasonic GH2 with Lumix G14 mm/F2.5 and Battery
)
534g(
@
Panasonic GH2 with Lumix G20 mm/F1.7 and Battery)
Controlled Angle
Accuracy
±0.05°
Maximum Controlled Rotation Speed
Pan axis: ±130°/s
Tilt axis: ±130°/s
Roll axis: ±30°/s
Controlled Rotation Range
Pan axis control: ±360° continuous rotation
Tilt axis control: ±360° continuous rotation
Roll axis control: ±40°
(±360° mechanic continuous rotation)
Regulatory Approvals
FCC (USA)
Yes
IC (Canada)
Yes
ROHS(EU)
Yes
