Assistant
Install Driver and Software
STEP1: Make sure driver is installed correctly, which has been installed before you use WKM
，ACE
ONE or ACE WAYPOINT.
STEP2: Please download assistant software ZenmuseInstaller.exe from DJI Innovations website.
STEP3: Double click ZenmuseInstaller.exe file and follow the steps to finish installation.
STEP4: Run DJI Zenmuse Assistant.
GUI
Connect GCU and PC via USB cable, power on GCU.
1
2
4
3
5
1 DJI
· Tools: Upgrade. For upgrading the
gimbal firmware
· Language: 中文or English
· Help: About. For version and SN access
2 Gimbal
· Basic: For Roll/Tilt/Pan/Mode observation
· Function: For Shutter/HDMI/AUX2
observation
Communication indicator
· Blue LED On: Without communication
· Green LED Blink: Communicating with PC
4
· Blue LED On: Disconnected with PC
· Green LED On: Connected with PC
3
Text Description 5
Connection indicator
· Mouse over each item will display the
corresponding content
