76 — C
ONSTRUCTION
M
ASTER
®
P
RO
/ T
RIG
/ D
ESKTOP
Stairs —
Given Rise and Run, Using “Riser Limited” Function
for Code Restrictions
Your local code prohibits risers greater than 7-1/2 Inches. You need
to build a stairway with a floor-to-floor height of 10 Feet 1 Inch, a run
of 15 Feet 5 Inches. Calculate all stair values. Use the “Riser
Limited” function (second function of the
s
key) to calculate a
riser height that does not exceed the stored Desired Riser Height of
7-1/2 Inches.
KEYSTROKE
DISPLAY
1. Enter Rise and Run:
o o
0.
1 0 f 1 i r
RISE 10
FEET
1
INCH
1 5 f 5 i R
RUN 15
FEET
5
INCH
2. Find stair values using “Riser Limited”:
Ç s
(Riser Limited)
R-HT 7-1/8
INCH
s
RSRS 17.
s
R+/– 1/8
INCH
s
T-WD 11-9/16
INCH
s
TRDS 16.
s
T+/– 0
INCH
s
OPEN 12
FEET
2-1/16
INCH
s
STRG 18
FEET
1-5/16
INCH
s
INCL 31.64°
s
RUN
15
FEET
5
INCH
s
RISE
10
FEET
1
INCH
s
R-HT
7-1/2
INCH
s
T-WD
10
INCH
s
HDRM
6
FEET
8
INCH
s
FLOR
10
INCH
STORED
STORED
STORED
STORED
STORED
STORED
