U

SER

S

G

UIDE

— 59

Angle and Diagonal (Hypotenuse)

Find the Diagonal (Hypotenuse) and degree of angle of a right trian-
gle that is 9 Feet high and 12 Feet long.

KEYSTROKE

DISPLAY

1. Enter Rise and Run:

o o

0.

9 f r

RISE 9

FEET

0

INCH

1 2 f R

RUN 12

FEET

0

INCH

2. Solve for Diagonal/Hypotenuse and Pitch in Inches and Degree of
Angle:

d

DIAG 15

FEET

0

INCH

p

PTCH 9

INCH

p

PTCH 36.87°

Rise

Find the Rise given a 7/12 Pitch and a Run of 11 Feet 6 Inches.

KEYSTROKE

DISPLAY

o o

0.

7 i p

PTCH 7

INCH

1 1 f 6 i R

RUN 11

FEET

6

INCH

r

RISE 6

FEET

8-1/2

INCH

Rise and Diagonal

Find the Rise and Diagonal of a right triangle given a 30° Pitch and
a run of 20 Feet 4 Inches.

KEYSTROKE

DISPLAY

o o

0.

3 0 p

PTCH 30.00°

2 0 f 4 i R

RUN 20

FEET

4

INCH

r

RISE 11

FEET

8-7/8

INCH

d

DIAG 23

FEET

5-3/4

INCH
