44 — C
ONSTRUCTION
M
ASTER
®
P
RO
/ T
RIG
/ D
ESKTOP
(Cont’d)
KEYSTROKE
DISPLAY
2. Enter chord length and segment height (rise):
o o
0.
1 5 f R
RUN 15
FEET
0
INCH
5 f r
RISE 5
FEET
0
INCH
3. Find Arc angle:
a
ARC 134.76º
4. Find Arc length:
a
ARC 19
FEET
1-5/16
INCH
5. Display entered chord length:
a
CORD 15
FEET
0
INCH
6. Find segment area:
a
SEG 54.19722
SQ FEET
7. Find pie slice area:
a
PIE 77.63472
SQ FEET
8. Display entered segment height (rise):
a
RISE 5
FEET
0
INCH
9. Display stored On-center spacing for the wall:
a
OC
16
INCH
10. Find arched segment wall lengths:
a
AW 1 4
FEET
10-11/16
INCH
a
AW 2 4
FEET
6-5/8
INCH
a
AW 3 3
FEET
11-3/8
INCH
a
AW 4 3
FEET
0-1/16
INCH
a
*
AW 5 1
FEET
6-1/4
INCH
11. Change arched walls preference setting back to “outside” Arc:
З Я Я Я Я Я Я
AW inSidE
+
AW outSidE
o
0.
*Successive presses of
a
will toggle to the beginning.
STORED
