14 — C

ONSTRUCTION

M

ASTER

®

P

RO

/ T

RIG

/ D

ESKTOP

Roof Materials/Covering Function

The

Construction Master Pro's Roof

function provides a quick calcu-

lation of roof area, number of squares and bundles, and number of
4 x 8 sheets required for roof coverage.

Ç d

Roof

— Given an entered Pitch (or Rise and Run)

and plan area (or Length and Width), calculates
the following:

Press Result
1

Roof Area (ROOF)

2

Number of Roof Squares (SQRS)

3

Number of Roof Bundles (BNDL)

4

Roof Bundle Size* (B-SZ)

5

Number of 4 x 8 Sheets (4

X

8 )

6

Pitch (PTCH)

7

Plan Area (PLAN)

*Roof bundle size is 33.33 Square Feet.

Stair Key

The

Construction Master Pro

easily calculates stair layout solutions.

With entered values for floor-to-floor rise and/or run, it will calculate
Riser, Tread, Stringer, and Incline Angle values simply by pressing
the

s

key.

s

Stair

— A multi-function key that uses a stored Riser

Height, stored Tread Width, stored Headroom
Height and Floor Thickness, and entered Rise and
Run values to calculate and display the following:

Press Result
1

Actual Riser Height (R-HT)

2

Number of Risers (RSRS)

3

Riser Overage/Underage (R+/-)

4

Tread Width (T-WD)

5

Number of Treads (TRDS)

6

Tread Overage/Underage (T+/-)

7

Stairwell Opening (OPEN)

8

Stringer Length (STRG)

9

Incline Angle* (INCL)

10

Run of Treads (RUN)

11

Floor-to-Floor Rise (RISE)

(Cont’d)
