Page 6
3. Distintive characteristics
The V300,V600 and V1000 are height measuring instruments, self-contained, controlled by a
microprocessor.
o
Easy to operate.
o
Self-contained operation for a period of: without air cushion : max.100h.
: with air cushion : max. 50h.
o
Rechargeable battery.
o
Big display.
o
Acceptance of measured values by an acoustic signal.
4. Specifications
Designation V300 V300C V600 V600C V1000 V1000C
Measuring range 300 mm or 12’’ 600 mm or 24’’ 1000 mm or 40’’
Application range 535 mm or 21’’ 835 mm or 32.8’’ 1235 mm or 48.6’’
Resolution 0.01 mm / 0.001 mm or .0005’’ / .00005’’
Overal measuring accuracy 3 µm + (L(mm)/300 = µm or .00012’’ + (L(inch)/300000) = inch
Repeatability ± 2 s = ≥ 2 µm or .00008’’
Max. displacement speed
of the measuring carriage 3m/120’’ per second
Measuring pressure 0.7 N – 1,6 N (adjustable)
Measuring system differencial capacitance Sylvac (patented)
Power supply Battery powered (rechargeable)
Operational time 100 h. 50 h. 100 h. 50 h. 100 h. 50 h.
Squareness deviation overal
(in measuring direction) 5µm or .0002’’ 8 µm or .0003’’ 12 µm or .00047’’
Data output RS 232 C
Operational temperature
limit + 10 °C to +40°C or 50° F to 104° F
Total height 565 mm or 22.2’’ 865 mm or 34’’ 1275 mm or 50’’
Weight 10 kg 12,3 kg 15,3 kg
5. Delivery
The TRIMOS V300, V600 and V1000 are supplied as follows :
o
Ruby ball probe dia. 4 mm (V-1)
o
Hex screwdriver wrench 2 mm (T016-INB.2), Hex screwdriver wrench 2,5 mm (T016-
INB.3)
o
AC adaptor set 8.5V / 700mA sector, depending on country.
o
Dust cover.
o
Test and guarantee certificates, user’s manual.
Vertical automatic Code number
without air cushion
Code number
with air cushion
Measuring range 300mm /12’’, 220 V V300/220 V300C/220
Measuring range 300mm /12’’, 240 V V300/240 V300C/240
Measuring range 300mm /12’’, 110 V V300/110 V300C/110
Measuring range 300mm /12’’, 100 V V300/100 V300C/100
Measuring range 600mm /24’’, 220 V V600/220 V600C/220
Measuring range 600mm /24’’, 240 V V600/240 V600C/240
Measuring range 600mm /24’’, 110 V V600/110 V600C/110
Measuring range 600mm /24’’, 100 V V600/100 V600C/100
Measuring range 1000mm /40’’, 220 V V1000/220 V1000C/220
Measuring range 1000mm /40’’, 240V V1000/240 V1000C/240
Measuring range 1000mm /40’’, 110 V V1000/110 V1000C/110
Measuring range 1000mm /40’’, 100 V V1000/100 V1000C/100
