1. Description of the instrument
1. Handwheel allowing the displacement of the measuring probe.
2. Locking device to activate the fine ajustment.
3. Fine adjustment screw.
4. Switch to acivate the air cushion. (Version C)
5. Handle allowing the displacement of the instrument.
6. Measuring probe.
7. Screw to adjust the measuring pressure (0.7N-1.6N, ajustable) (wrench /2mm)
8. Lever for fast displacement.
9. Screw for locking the measuring carriage (wrench 2mm) (Screw, chromium-
plated)
10. Control screw to ajust the floating probe suspension. (wrench 2mm)
11. Bracket for printer.
12. Printer RS 232.
13. RS 232 connector.
14. Green light = Indicates the trickle charge with AC adapter connected.
15. Red light = Indicates fast charging.
16. Connector for AC adaptor or data transmission foot pedal.
17. Green light = normal measuring mode.
18. Orange light = measuring diameters.
19. Yellow light = measuring centerlines.
20. NORMAL or DIAMETER/CENTERLINE mode key.
21. PRESET key = set the display at zero or memorizes preset values.
22. PRINT key = RS232 data output.
23. ON-OFF key = ON / OFF Switch.
24. Numerical keyboard.
25. CLEAR key = reinitialises the minimum/maximum/delta memories.
26. MIN/MAX/DELTA mode key.
27. MM/INCH key, true conversion Metric – Inch – Metric.
28. REF I / REF II selection key.
29. Resolution key. (0.010/0.001mm or .0005/.00005”)
30. Probe constant key.
2. Display functions
31. Indication of sending data.
32. Indication of DELTA mode.
33. Indication of MAX mode.
34. Indication of MIN mode.
35. Indication of REFII mode.
36. Indication of low battery level – connect the AC adaptor.
37. Indication of measuring values.
38. Indication of MM mode.
39. Indication of INCH mode.
40. Indication of measuring direction.
41. Indication of centerline mode.
42. Indication of diameter mode.
43. Indication of PRESET mode.
44. Indication of CONSTANT mode.
45. Indication of keyboard locked.
