87
Chapter 9 Computer Software
The Bird Site Analyzer Software is designed to help
you use the Site Analyzer more effectively. The
software enables use of a PC for archiving and
analyzing measurement data.
Features
!
Multiple Document Interface - allows any number
of trace documents to be open simultaneously.
!
Intelligent drag-and-drop automatically converts
traces to a common scale for precise and reliable
comparisons.
!
Documents can be viewed in the frequency or
distance domains, or as a Smith chart.
! Data values can be read off the status bar as the
mouse is moved along the trace.
! Compatible with other cable and antenna testers
including the Bird AT Series.
☞
NOTE: The Bird Site Analyzer and PCTool
software are not compatible with trace data from
the Anritsu Site Master.
!
Automatic cursor calibration maintains accurate
readouts of trace data even if the x-axis changes.
!
Supports long file names for easy identification.
Computer Requirements
To install and run the software, your computer system
must meet the following requirements:
! Windows 95 or later
!
486 or better microprocessor running enhanced
mode (66 MHz or better recommended)
! 1 MB of free memory
! Hard disk with 3 MB of free space
! 1.44 MB Floppy Drive
☞
NOTE: For more instructions refer to the help files
included with the software.
