33
Chapter 5 Fault Location Mode
This measurement identifies the position of impedance
discontinuities (faults) within the antenna/feeder
system. The measurement results are displayed on an
x-y graph. Distance from the Site Analyzer is shown
on the x-axis, while relative magnitude of the
discontinuity is shown on the y-axis.
☞
NOTE: For best results, set the frequency span,
the cable type, and calibrate the Site Analyzer
immediately before taking measurements.
Press the
Mode key
Press from
Select Mode 0.0 Meters 18.2
Fault Location Mode
Calibration: Full
1.70
1.00
V
S
W
R
Save/
Recall
Auto
Scale
Limit
Test On
Run
Print
