Fault Location Mode

49

Move

across the

trace

Locate the

highest

point of the

trace

Locate the

lowest point

of the trace

M1

Active

M2

On

∆M

Single

0.0

Meters

18.2

Fault Location Mode

Calibration: Full

1.70

1.00

V

S

W

R

M1: 13.1 m

M2: 8.4 m

∆M: 4.7 m

1.32

1.20

0.12

M2

M1
