Bird Site Analyzer
92
Battery Replacement
! Lay the Site Analyzer, display side down, on a clean
surface.
!
Remove the four screws and the battery cover. Refer
to the figure below.
☞
NOTE: Check the direction of the notch in the
battery cover. It is important to replace the cover
the same way it was removed.
!
Disconnect and remove the old battery pack from
the battery compartment.
☞
NOTE: Do not tear the protective label covering
the EPROM and Reset access. Hold the wires
coming from the unit while disconnecting the
battery.
! Install the new battery. Make sure the wires are
firmly connected.
!
Place the battery in the battery compartment. Make
sure the battery is flat in the compartment, and will
not damage any wires when the cover is installed.
!
Replace the battery cover and the screws.
