Maintenance
27
Specifications
Impedance 50 ohm nominal
VSWR 1.10:1 maximum, 1.05:1 typical
*
Connectors (Model Dependent)
1-5/8” EIA Flanged 1-5/8” Unflanged
3-1/8” EIA Flanged 3-1/8” Unflanged
4-1/16” Myat Flanged 4-1/16” Myat Unflanged
4-1/2” IEC Unflanged 4-7/8” IEC Unflanged
6-1/8” EIA Flanged
Power Rating
DA5 Series
DA10 & DA10V Series
DA15 Series
DA25 & DA25V Series
DA40 Series
5 kW continuous duty
10 kW continuous duty
15 kW continuous duty
25 kW continuous duty
40 kW continuous duty
Peak to Average Power Ratio
†
Model DA40 series only
All other models
>14dB
>10dB
Frequency Range
DA10V & DA25V Series
DA5, DA10, DA15, DA25, &
DA40 Series
DC-240 MHz
470-890 MHz
Dimensions
DA10V Series
DA25V Series
DA5 Series
DA10 Series
DA15 Series
DA25 Series
DA40 Series
23.5"L x 23.5"W x 59"H (597 x 597 x 1499 mm)
27"L x 27"W x 61.0"H (686 x 686 x 1549 mm)
17"L x 17"W x 64.0"H (432 x 432 x 1626 mm)
19.5"L x19.5"W x 68.5"H (495x495x1740mm)
25"L x 25"W x 76.5"H (635 x 635 x 1943 mm)
27"L x 27"W x 76.5"H (686 x 686 x 1943 mm)
27.5"L x 27.5"W x 84.0"H (701x701x2134 mm)
Ambient Temperature -40°C to +45°C (-40°F to +113°F)
Storage Temperature -40°C to +70°C (-40°F to +158° F)
Humidity 30% to 95% (non-condensing)
Altitude See Figure 14 and Figure 15
Interlock contact rating 10 Amp @ 120 VAC
5 Amp @ 250 VAC
