1
Chapter 1 Introduction
Figure 1 Digital Air Outline Drawing
Series Dim. A Dim. B Dim. C Dim. D Dim. E Dim. F Dim. G
DA10V 23.5”
(597 mm)
23.5”
(597 mm)
49.5”
(1257 mm)
59”
(1499 mm)
N/A
*
*. Forklift openings are not provided for these models.
N/A
1
N/A
1
DA25V 27.0”
(686 mm)
27.0”
(686 mm)
50.8”
(1289 mm)
61.0”
(1549 mm)
N/A 1 N/A 1 N/A 1
DA5 17.0”
(432 mm)
17.0”
(432 mm)
55.5”
(1410 mm)
64.0”
(1626 mm)
N/A
1
N/A
1
N/A
1
DA10 19.5”
(495 mm)
19.5”
(495 mm)
60.0”
(1524 mm)
68.5”
(1740 mm)
N/A
1
N/A
1
N/A
1
DA15 25.0”
(635 mm)
25.0”
(635 mm)
68.0”
(1727
mm)
76.5”
(1943
mm)
24.5”
(622 mm)
6.0”
(152 mm)
2.0”
(50.8 mm)
DA25 27.0”
(686 mm)
27.0”
(686 mm)
68.0”
(1727
mm)
76.5”
(1943
mm)
24.5”
(622 mm)
6.0”
(152 mm)
2.0”
(50.8 mm)
DA40 27.5”
(701 mm)
27.5”
(701 mm)
78.8”
(1999 mm)
84.0”
(2134 mm)
24.5”
(622 mm)
6.0”
(152 mm)
2.0”
(50.8 mm)
