Do not place the unit in a small room or closet without proper
ventilation.

Note:

In restricted areas the heat given off by the unit may

increase the ambient temperature to an unacceptable level.

z

Fan intake openings should be at least 4 inches from walls and
obstacles.

Note:

Intake air should not exceed maximum ambient

temperatures of 45°C.

z

The air exit duct should be at least 24 inches from walls and
obstacles.

z

Do not place temperature sensitive equipment near the air
exit, or equipment that will be affected by a rise in ambient air
temperature.

Note:

Exit air temperatures can reach in excess of 95°C

depending on environmental conditions.

Ducting Placement

Ducting the unit exhaust is recommended for larger models. Mounting

nuts are provided on the rear of the unit for ducting. Refer to Figure 3

for the location of the mounting nuts.
Should an external duct be desired, make sure the following require-

ments are met:

z

Maximum 0.2" H

2

O pressure rise at 45°C ambient.

z

All ducts should be at least the area of the air exit duct on the
unit. Refer to Figure 3.

z

Ninety degree elbows going up to the ceiling may begin imme-
diately at the load exit. However, they should have a mini-
mum 4 inch radius, >15 inches preferred and should transition
to a larger area.

z

Ninety degree elbows into the floor or at right angles to the
floor should start a minimum 5 inches from the load exit and
should have a minimum 4 inch radius, >15 inches preferred
and should transition to a larger area.

CAUTION

Do not block airflow. Air is forced into the housing

via fans on all four sides and exhausts through a

grille on the lower rear of the unit. Blocking air

inputs or exhaust could cause unit failure.
