24
Circuit Diagram
The following circuit diagram identifies the function of the internal
wiring of the load. This information is for use by trained service per-
sonnel only.
WARNING
Improper wiring could result in electric shock and
death.
WARNING
Turn off AC power and RF power before removing or
replacing the access panel, the potential for electrical
shock exists.
WARNING
High heat present inside unit! Let cool for at least 10
minutes before servicing or severe burns could result.
WARNING
Maintenance by other than trained service personnel
could result in electric shock.
CAUTION
Improper wiring could disable load.
CAUTION
Do not disable fans. Application of full RF power to
the load while the air circulation is off will cause the
load to overheat and destroy the resistor elements.
CAUTION
All replacement wiring must be 18 AWG, with
insulation rated to 400º F (205º C). Use of other
wiring could result in unit damage.
CAUTION
This circuit diagram for use by trained service
personnel only. Improper use could disable load.
