Bird AT-800 Antenna Tester
36
Select Measurement Units
Antenna match information can be presented in Rho,
VSWR, %Match or Return Loss units.
1. Press the MENU key.
2. Press the MEAS MATCH key.
3. Press the SINGLE FREQ key.
4. Press the UNITS key.
5. Press either the RHO, VSWR, %MATCH or
RETURN LOSS key.
Note: The selected unit will be shown in
the center of the display.
6. Press the RETURN key to go back one menu level.
Select Auto or Manual Scale
1. Press the MENU key.
2. Press the MEAS MATCH key from the top level
menu.
3. Press the SINGLE FREQ key.
4. Depending on desired method press either AUTO
or MANUAL SCALE:
Auto Scale
The units scale changes.
