Basic Operations
13
Follow the steps below to select the length of time,
before auto shut-off occurs.
1. Press the MENU key.
2. Press the UTIL key.
3. Press the TIMER key until the desired interval is
displayed.
Return to Factory Presets
When the Antenna Tester is turned on, the various soft-
ware parameters will be set to the condition they were
at when the tester was turned off. To return the param-
eters to the factory setting follow the steps below.
Note: The parameters will return to these
settings:
1. Press the MENU key.
2. Press the UTIL key.
3. Press the PRESET key.
Software Parameter Factory Setting
Cellular System AMPS Mobile
Frequency Band User; 806MHz -960MHz
Measurement Units VSWR
Scale min. 1.0; max. 5.0
Mode Swept Frequency
Sweep Type Continuous
Baud Rate 9600
Auto Shut-off Timer 5
Audio Off
