Introduction
5
1. Sweep Rate
Indicator
Blinks when sweeping.
2. Measurement Units Indicates selected measurement
units.
3. Trace Graphic display of measured
results across selected frequency
band.
4. Menu Select Key
Labels Defines function of menu select
keys located below the display.
5. Frequency Band
Scale Displays frequency band selected.
6. Cursor Used to select measurement
position on the trace.
7. Utility Label Area for displaying general data
(Lo Batt, Busy, Hold, Noise, and
test results).
8. Band Indicates selected band for cellular
system defined, (Tx, Rx, TxRx, or
User).
9. Base/Mobile
Indicator
Indicates Base or Mobile selection.
10. Cellular System Indicates cellular system selected
(AMPS, GSM, PDC, CT-2, CT-2
Korea).
11. Frequency Selected Frequency (for swept
mode this is frequency at the
cursor position).
12. Measured Value Numeric display of measured value
(for swept mode this is the value at
the cursor position).
13. Scale Displays user defined
measurement scale.
14. Pointer Moves across scale to show
analog indication of measured
value.
15. Channel Channel number corresponding to
selected frequency.
