Bird AT-800 Antenna Tester
32
Turn Audio On/Off
Audio tone for fail indication.
1. Press the MENU key.
2. Press the MEAS MATCH key.
3. Press the SWEPT FREQ key.
4. Press the LIMIT key.
5. Pressing the AUDIO key will toggle between on
and off.
Selecting Limit Values
Valid limit values depend on measurement units
selected. Valid entries are:
z VSWR
Note: Between 1.0 and 100.0
z % Match
Note: Between 0 and 100%
z Return Loss
Note: Between -32 and 0 dB
z RHO
Note: Between 0.000 and 1.000
To set the limits:
1. Press the MENU key.
2. Press the MEAS MATCH key.
3. Press the SWEPT FREQ key.
