Bird AT-800 Antenna Tester
2
Component Description
Figure 2 Component Description
1. LCD Display Backlit liquid crystal display.
2. External DC
Connector Connect either the ac adapter or the
cigarette lighter adapter cable. External
supplies operate the unit and charge
the internal battery.
