Figure 9 Auto Scaling Single Frequency Mode

Figure 10 Manual Scaling Single Frequency Mode

Sweep Type – Single Hold vs. Continuous

Continuous sweep continually sweeps the frequency
band and updates the value after each sweep. An
asterisk (*) blinks on the left side of the display to indi-
cate sweep rate. Single hold mode will freeze a trace
on the display and show hold on the right. Holding a
trace before saving it is helpful.

AMPS

Mobile

VSWR

1.2

1.5

1.35

858.27 MHz

Freq
MHz

Units

Manual
Scale

Auto
Scale

Audio
Off
