25
Situation Possible Solutions
IR camera image is not displayed after the
Bendix logo fades away on the display.
Wait two minutes after the Bendix ® XVision ® Night Vision Sys-
tem has been powered to view the IR camera image.
Check to see if the IR camera window is blocked.
Headlamps were turned off and the XVision system timed out
(approximately 7 seconds after the headlamps are turned off
the display will turn off.)
Check to see if the IR camera is aimed correctly.
Display image is upside down. Check that DIP switch 4 is set correctly. Reference figure 14 on
page 8.
Check that DIP switch 3 is set correctly. Reference figure 14 on
page 8.
Check to see if the display intensity is set correctly.
Check that the combiner is open to an angle that allows you to
see the image.
Check to see if the combiner, fold mirror, and LCD are clean.
Check to see if the IR camera window is cracked. Moisture
between the window and lens will limit image quality.
2-pin Description Voltage
A IR camera heater + 12 Volts
power
B IR camera heater ground
power
Display image is reversed, right to left.
The display image is difficult to view.
Check the 2-pin IR camera harness connector is plugged into
the IR camera heater. Reference figure 21 on page 11.
Check that the terminals are seated and the wiring is secure.
Check the 2-pin IR camera harness connections. Reference the
XVision system schematic, figure 43 on page 23 @ +
Snow build up on the IR camera window with the
Bendix ® XVision ® Night Vision System powered.
Please note that this product is obsolete and parts/kits listed in this document
are no longer serviceable through Bendix.
For any inquiries regarding this system, call the Bendix technical assistance
team at 1-800-AIR-BRAKE (1-800-247-2725), Monday through Friday, 8:00
A.M. to 6:00 P.M. EST.
Alternatively, you may e-mail the Bendix Tech Team at: [email protected].
