18
Display Replacement
IMPORTANT: The display is not waterproof and
should not be exposed to rain, snow, or moisture.
Under extreme conditions, water may enter the
circuitry through the panel buttons. In general, treat
the display as you would a pocket calculator or other
small non -waterproof electronic instrument.
IMPORTANT: The Bendix ® XVision ® Night Vision
System display technology is designed to meet
severe temperature extremes. However, when
installing the display for head-down operation or
for use in extremely warm climates, take necessary
precautions to shield the unit from direct sunlight.
Prolonged exposure to direct sunlight in enclosed
truck cabs can damage the system.
CB Style Mount (Dashboard and/or Overhead)
1. Unscrew and disconnect the 25-pin connector of the
display harness.
2. Unscrew the threaded knobs from the display and
brackets. Refer to Figure 30. Set the knobs and
washers aside.
3. Remove the old display.
4. Set the DIP switches on the new display according to
Table 5 on Page 7.
5. Slide one of the washers onto one of the threaded
knobs.
6. Hold one washer between the new display and a
bracket while threading the washer/knob from the
outside of the bracket. Refer to Figure 30 on Page 15.
7. Repeat steps 5 and 6 for the other side of the display.
8. Plug the 25-pin connector of the display harness into
the new display.
Friction Hinge Mount (Visor)
1. Disconnect the 25-pin connector of the display harness.
2. Flip the display down to allow access to the friction
hinge supports.
3. Remove the four #10 Plastite ® pan head screws that
secure the display to the headliner.
4. Remove the old display.
5. Remove the two M2.5 threadroll pan head screws that
secure the friction hinge supports to the display.
6. Secure the friction hinge supports to the new display
with the two M2.5 threadroll pan head screws.
IMPORTANT: Do not exceed 15 in-lbs. when
fastening. If 15 in-lbs. are exceeded, the screw head
will shear off or the standoffs will strip. The threadroll
screws will form the threads on the standoffs as
they are tightened. If it feels as though the screw is
binding, back out the screw slightly and continue to
tighten to prevent breakage.
7. Secure the friction hinge supports to the headliner with
the four #10 Plastite ® pan head screws.
8. Torque the screws to approximately 15 in-lbs.
9. Connect the 25-pin connector of the display harness
to the new display.
HARNESS REPLACEMENT
Each of the XVision System harnesses is replaceable and
can be ordered through Bendix. Refer to Figure 43 on page
22 for more detailed information regarding the electrical
wiring of the system.
IR camera Harness
1. Remove the trim pieces covering the harness and
the cab headliner in areas covering the IR camera
harness.
2. Disconnect the 8-pin connector of the IR camera
harness from the display harness.
3. Turn the two IR camera aiming adjusters and the IR
camera standoff pivot assembly 1/4 turn.
4. Remove the IR camera from the IR camera bracket
to gain easier access to the connectors.
5. Disconnect the IR camera connector (6-pin) and the
window heater connector (2-pin) of the IR camera
harness.
6. Cut the cable tie that secures the IR camera harness
to the IR camera mounting bracket.
7. From inside the cab, remove the externally threaded
nut from the harness.
8. Remove the IR camera harness from the cab.
9. Remove the externally threaded nut from the heat
shrinkable shroud assembly on the replacement
harness.
10. From inside the cab, push the threaded nut through
the hole in the roof.
NOTE: The threaded section of the nut should
protrude past the vehicle surface. Refer to Figure
31.
11. Place the o-ring over the externally threaded end.
12. Thread the harness through the externally threaded
nut.
13. Fasten the heat shrinkable shroud onto the nut.
14. Hand-tighten the shroud from the outside of the roof.
15. Torque the heat-shrinkable shroud with a spanner
Parts/kits listed are now obsolete and are no longer serviceable through Bendix.
