AJA FS1 User Manual
Page 80
72
Output Format (1.1)
Video In (2.1)
NTSC Standard (3.4)
Audio In (2.2)
Frame Rate (3.3)
Component In (3.1)
Component Out (3.2) Signal Type
Follow Input (default)
Follow Ref
SD
HD 720p
HD 1080i
HD 1080psf
Output follows the format of the selected input
Output follows the format of the reference video input (Ref)
Output is standard definition (available SD rates are listed choices)
Output is HD 720p (available rates are listed choices)
Output is HD 1080i (available rates are listed choices)
Output is HD 1080psf (available rates are listed choices)
SDI 1 (default)
SDI 2
Composite
S-Video
Component
Select SDI 1 connector as the input source
Select SDI 2 connector as the input source
Select the Composite connector as the input source
Select the S-Video connector as the input source
Select the Component connector as the input source
NTSC (default)
NTSC Japan
Select NTSC for US NTSC standard
Select NTSC Japan for NTSC standard
Embed Auto
(Follows Video Input select)
Embed SDI 1
Embed SDI 2
AES unbal (default)
Analog
Use the embedded audio from the currently selected Video Input (SDI 1 or 2) as the
input source. (This defaults to SDI 1 if Video In is not SDI.)
Use the embedded audio from the SDI 1 connector as the input source
Use the embedded audio from the SDI 2 connector as the input source
Select the AES/EBU digital audio connectors (8-ch) as the audio input source
Select the Analog audio connector (DB25, 8-ch) as the audio input source
59.94/23.98 (default)
60/24
50/25
Select the “59.94/23.98” item if your desired rate is either 59.94
or 23.98
Select the “60/24” item if your desired rate is either 60 or 24
Select the “50/25” item if your desired rate is either 50 or 25 (PAL)
Beta YPbPr
SMPTE YPbPr (default)
Configure the Component video input source as Beta YPbPr (Standard Definition)
(If the selected Component video source is HD, this will default to SMPTE YPbPr)
Configure the Component video input source as SMPTE YPbPr
Beta YPbPr
SMPTE YPbPr (default)
RGB
Configure the Component video output as Beta YPbPr (Standard Definition)
(If the Component video is HD, this will default to SMPTE YPbPr)
Configure the Component video output as SMPTE YPbPr
Configure the Component video output as RGB
